Temperature Transmitter
Temperature Transmitter
Couldn't load pickup availability
Temperature Transmitter
5-year stability, up to 0.1°C accuracy
Improve system accuracy by 75% by matching transmitter to sensor
Polished stainless steel housing for sanitary and biopharmaceutical applications
Integrated LCD display for easy display of process temperature and diagnostic information
Customizable modular platform to meet your needs with a single model
Single or dual sensor inputs for RTD, thermocouple, millivolt or ohm
Special models and products can be customized
Technical Parameters
| Measuring range |
-50~1600℃ |
| Output signal |
4-20mA/ Resistance/ other |
| Signal line specifications |
2 Wire |
| Temperature measuring element |
PT100,PT1000,B,E,J,K,N,R,S,T |
| Accuracy |
Level Ⅰ, Level Ⅱ, Level Ⅲ |
| Long-term stability |
±0.1%FS/ year |
| Response time |
T=50℃ 2.3s,T=90℃ 5.4s |
| Pressure resistance |
400bar |
| Operating temperature |
-40℃~+125℃ |
| Storage temperature |
-40~+125℃ |
| Housing Material |
304/ Precious metal customization |
| Media compatibility |
304/ Precious metal customization |
| Installation |
Threaded installation or other |
| Protection level |
IP65 |
| Electrical connections |
Gland |
